Power source

AC100V~240V 50/60HZ

DC12V 3A

voltage

24/36/60W

Motor speed

18000±15%

Spindle speed

3000±15%

Large slider stroke (Z axis)

45mm

Small slider stroke (X axis)

35mm

Collet size

ф1、ф2、ф2.5、ф3

ф3.5、ф4、ф5、ф6

Chuck diameter

48mm

Dividing plate

Outer Diameter: 88mm

Inner Diameter: 26mm

Dial parameters:36,40,48 holes respectively

Product size

278*100*150mm

Packing size

352*200*240mm

Net Weight

2.7kg
