Product Features:

1. The machine comes standard with an industrial‑grade CNC system, which uses a 32‑bit high‑performance industrial CPU as the control core to achieve micron‑level precision motion control. The system is powerful, stable in performance, and features an intuitive, clear interface for easy operation. Other mainstream CNC systems such as Guangshu and KND can be equipped upon user request.

2. The machine provides high precision, includes a protective cover and cooling system, and can automatically turn various rotational surfaces (e.g., cylindrical, conical, and specially shaped surfaces). It also performs threading, boring, and reaming operations with high efficiency and strong adaptability.

3. The bed guideways are precision‑ground after ultra‑audio frequency quenching, delivering high hardness and rigidity. The headstock, guideways, saddle, and slide are designed with generous dimensions.

4. The saddle undergoes special treatment to ensure smooth movement, reduce wear on the bed guideways, and prevent stick‑slip phenomena. It offers high precision and long service life. The ball screw adopts an integrated internal‑circulation design, supported by pre‑loaded angular contact ball bearings. Centralized lubrication is applied to the guideways and screws, providing flexible movement, reduced thermal deformation, and stable accuracy.

5. Equipped with an electronic handwheel and a four‑station electric tool post that uses a precision tooth‑disc for positioning, ensuring high repeatability.

6. A servo control system is available as an option, offering fast response, quiet and smooth operation, as well as high efficiency and precision.

7. Optional high‑grade tools can achieve a workpiece surface roughness of up to Ra0.8.

8. Optional rear‑mounted or front‑mounted automatic chucks and automatic feeding devices are available.

9. The machine is compatible with FMS (Flexible Manufacturing System) and can be customized for automation according to customer requirements.

10. It features an aesthetically pleasing design with a user‑friendly human‑machine interface for convenient operation.

11. Main processable materials include ferrous metals, copper, aluminum, and other non‑ferrous metals.
